Showing 256–270 of 610 results
-
- 3/4" NPSM (20mm) 'M' thread
- 1/2" (13mm) throat entry
- Straight bore
- Tungsten carbide liner
- Aluminum jacket and thread
- Use HF GFBS-P nozzle washers (1 included)
-
BNATC360CThe 360° internal pipe blasting nozzle is ideal for use when blast cleaning small interior pipes ranging in size from 65 - 125mm in diameter.
- Wear-resistant angle type blasting nozzle
- Made from tungsten carbide
- Up to 400 hours of blast life
- Aluminum thread, 50mm for NHP nozzle holder
- Aluminum jacket
BNATC360CThe 360° internal pipe blasting nozzle is ideal for use when blast cleaning small interior pipes ranging in size from 65 - 125mm in diameter.
- Wear-resistant angle type blasting nozzle
- Made from tungsten carbide
- Up to 400 hours of blast life
- Aluminum thread, 50mm for NHP nozzle holder
- Aluminum jacket
-
- Used for blasting pipes 3"-12" Internal Diameter
- Uses tungsten carbide deflection head and 1/2" throat nozzle
- Select the unit that will best match your Air Supply:
- 1/2" Throat Nozzle: 250 cfm
- 5/8" Throat Nozzle: 400 cfm
- Neither of these packages come with a transport carriage - Order Separately
- Collar and Button 3"-5" Pipes
- Scissor Type 5"-12" Pipes
- Successful Pipe Internal Projects require some specialist knowledge - contact our team for assistance
-
BNASB15MThe "Jumbo RotorBlast Blast Nozzle 5/16" (SKU: BNASB15M) is a high-quality tungsten carbide nozzle, perfectly designed for RotorBlast internal pipe blasting with a 5/16" (8.0mm) orifice and medium thread.- Blast Nozzle Jumbo RotorBlast
- Jumbo RotorBlast Blast Nozzle Tungsten Carbide, 5/16" (8.0mm) Orifice, Medium Thread
- Also fits spin blast / spinblaster
BNASB15MThe "Jumbo RotorBlast Blast Nozzle 5/16" (SKU: BNASB15M) is a high-quality tungsten carbide nozzle, perfectly designed for RotorBlast internal pipe blasting with a 5/16" (8.0mm) orifice and medium thread.- Blast Nozzle Jumbo RotorBlast
- Jumbo RotorBlast Blast Nozzle Tungsten Carbide, 5/16" (8.0mm) Orifice, Medium Thread
- Also fits spin blast / spinblaster
-
- Ideal for blasting recesses, pipe internals, behind angles, etc.
- 2" UNC (50mm) coarse Contractor thread 'C' or 1 1/4" NPSM (32mm) Fine Industrial thread 'F'
- 3/4" (20mm) throat entry
- 45° single or triple (equi-spaced) side outlets
- Tungsten carbide liner
- **Triple orifice nozzles have triple air & abrasive consumption!
-
BNASB17M- Blast Nozzle Jumbo RotorBlast
- Jumbo RotorBlast Blast Nozzle Tungsten Carbide, 3/8" (9.5mm) Orifice, Medium Thread
- Also fits spin blast / spinblaster
BNASB17M- Blast Nozzle Jumbo RotorBlast
- Jumbo RotorBlast Blast Nozzle Tungsten Carbide, 3/8" (9.5mm) Orifice, Medium Thread
- Also fits spin blast / spinblaster
-
- Pressure-release deadman control valve i.e., blast machine depressurizes when the deadman handle is released.
- Used when an overhead hopper automatically feeds abrasive into a blast machine.
- Rugged stainless steel body, compact, isolated 2-bolt construction.
- Doubles blast machine refill cycle time.
- Virtual Position Indicator illustrates orifice size, giving the ability to set abrasive flow quickly and consistently.
- Set and forget – flow rates stay set where you put them.
- High wear, rugged plunger seal.
- Stainless steel body for long life.
- Improved urethane clean-out port enabling quick removal of obstructions while improving port and valve life.
- Fit a rebuild kit while the valve is still fitted to the blast machine.
- Sold individually.
- Genuine Products – Manufactured by Schmidt / Axxiom Manufacturing
-
Enhance your blasting efficiency with the Schmidt® MicroValve Abrasive Metering Valve. Designed for precise abrasive flow, this rugged valve ensures optimal sandblasting media use.
- The MicroValve™ changed the industry by providing accurate metering valve
- Most pressure-release Schmidt pots now use the newer MicroValve® 3
- Simple screw type metering through a low-wearing valve
- 1 ¼" (32 mm) thread abrasive inlet port
- Hardened steel threaded base nipple
- Sold Individually, Brass Coupling not included
- Genuine Products - Manufactured by Schmidt® / Axxiom Manufacturing
- The MicroValve™ changed the industry by providing accurate metering valve
-
The Water Induction Nozzle (aka WIN nozzle) is an economical way to enter the wet blasting market. Commonly used in smaller projects, it offers excellent water flow control. Additional Details:
- Use with standard dry blasting equipment. No modifications required.
- Connects to standard garden hose, or you can use a tank with a standard 12v pump if you need to add rust inhibitor to the water.
- Typically stocked with tungsten carbide liner and contractor threads, it is also available with silicon nitride liner and/or fine threads. Contact us for details.
-
- 3/4" NPSM (20mm) 'M' thread
- 1/2" (13mm) throat entry
- 45° single or triple (equi-spaced) side outlets
- Tungsten carbide liner
- **Triple orifice nozzles have triple air and abrasive consumption!
-
INH131PBAGThe “Blast Nozzle Wear Size Analyzer Gauge” (SKU: INH131PBAG) efficiently determines the internal diameter and wear level of a blast nozzle orifice, ensuring optimal blasting performance.- Used to determine the internal diameter of a blast nozzle orifice
- Allows you to determine the level of wear of the blast nozzle
- Comes with a removable cap and crayon
- Has size markings to allow you to see quickly what size your nozzle is
- Sold Individually
INH131PBAGThe “Blast Nozzle Wear Size Analyzer Gauge” (SKU: INH131PBAG) efficiently determines the internal diameter and wear level of a blast nozzle orifice, ensuring optimal blasting performance.- Used to determine the internal diameter of a blast nozzle orifice
- Allows you to determine the level of wear of the blast nozzle
- Comes with a removable cap and crayon
- Has size markings to allow you to see quickly what size your nozzle is
- Sold Individually
Part Number Purchase Price INH131PBAG $152.40 Web price iPlease sign in to your account to see your pricing, which may be different from the price displayed.$152.40
-
-
- The original Thompson® Valve invented by Bob Schmidt
- Suits a pressure hold system, which retains the pressure in the blast pot, until the deadman handle is depressed
- Meters the flow of blasting grit, garnet abrasive sand
- 3 Nipple size configurations:
- 1 ¼ (32 mm) x 1 ¼ (32 mm)
- 1 ½" (38 mm) x 1 ½" (38 mm)
- 2" (50 mm) x 2" (50 mm)
- Threaded-plunger metering design with air actuated operation
- The Thompson® Valve is suitable for use with all approved blasting abrasives
- Fits most sand blast hoppers, blast pots or abrasive blasting machines
- Genuine Parts - Manufactured by Schmidt® / Axxiom Manufacturing
-
The industry-proven Schmidt TeraValve™ XL metering valve is revolutionary in its ability to provide high performance abrasive metering while boasting an enhanced service life.
- Durable. The XL (extended life) technology offers more durability - even when blasting with aggressive media like aluminum oxide or steel grit.
- Convenient. No special modifications are required to swap an older pressure-hold valve (like the Thompson) to a Tera. Even older pressure-release pots can be upgraded with a TeraValve Retrofit Kit, as long as there is at least 6" clearance from the bottom of the pot.
- Preferred. BlastOne provides the Tera Valve as standard equipment on all new blast equipment. In addition, we use them in our own rental fleet.
-
VAVacuInt55- Capacity of 4 tons of garnet
- Designed to sit between the VacuLoad and the vacuum head
- Separates abrasive and 90% of dust for reuse or disposal
- Available in 3 sizes – 20, 55, and 100 cu.ft
- Acts as a cyclone separator using power from the main vacuum unit
- No need for compressed air or electric power
- Ideal for abrasive storage
VAVacuInt55- Capacity of 4 tons of garnet
- Designed to sit between the VacuLoad and the vacuum head
- Separates abrasive and 90% of dust for reuse or disposal
- Available in 3 sizes – 20, 55, and 100 cu.ft
- Acts as a cyclone separator using power from the main vacuum unit
- No need for compressed air or electric power
- Ideal for abrasive storage
Part Number Purchase Price VAVacuInt55 Request Quote Web price iPlease sign in to your account to see your pricing, which may be different from the price displayed.Request Quote
-
-
The Schmidt Thompson® Valve II Blast Pot Retrofit Kit converts your existing blast pot into a pressure-hold system, reducing downtime and improving efficiency. Designed for stop/start blasting and multi-outlet blast machines, this OEM Schmidt®/Axxiom kit includes all necessary components for fast-response remote control operation.
Included in the Retrofit Kit:
- Thompson® Valve Series II Metering Valve
- Full pusherline kit
- Automatic air valve with interconnecting hoses
- Control line strainer and control valve
- Response deadman handle and Twinline
- Note: Does not include muffler or pressure relief valve
